Scope
It is suitable for supporting fields such as generator sets, tractors, lawn mowers, water pumps, small ship machines, etc.
Main Technical Parameters
EV80 | V402 | |||
Type | V-shaped, water-cooled, four-stroke | V-shaped, water-cooled, four-stroke | ||
Number of cylinders | 2 | 2 | ||
Cylinder diameter | 80 | 80 | ||
Stroke | 79 | 79 | ||
Total displacement | 0.794 | 0.794 | ||
Rated net power/speed | 12/3000 | 14/3600 | 14/3000 | 16/3600 |
Maximum net torque/speed | 43/2100-2500 | 55/1600-2200 | ||
Fuel system | Mechanical pump, electronic speed regulation | High voltage common rail | ||
Air intake mode | Naturally aspirated | Naturally aspirated | ||
Net mass (kg) | 58 | 60 | ||
Dimensions (L x W x H) | 650×486×528 | 440×514×540 | ||
Emission phase | / | Non-road countries IV and EU V stages | ||
